– Compensation cassettes are supplied ready for energization in modular Main Distribution Panels and Compensation Panels
– Controlled by electromechanical switching
– Unfiltered systems
Application Areas
- Compensation panels as per need
- Main distribution panels
- Existing compensation system revisions
C7s Series Compensation Cassettes | Advantages
- Compatibility with modular system structure
- Easy and quick installation
- Ease of service and maintenance
- Ease of MDP design thanks to modular design
- Maximum power in minimum floor space
- Possibility to use 5 modular cassettes on a single panel
- Safe design against touch and electric shock
- Use of high quality equipment
- Proven design developed since 2002
C7s Series Compensation Cassettes | Technical Specifications
- Rated Voltage : 220 - 720 V
- Nominal Frekans : 50 / 60 Hz
- Tuning Frequency : 134 - 225 Hz (50 Hz Network)
- Standard Steps : 12.5 / 25 / 50 / 75 kVAr
- Switching Equipment : Static Contactor
- Cooling : 1000 m3/h and above Cooling Fan
- System Design : Against harmonic currents and voltages at different levels
- Standard type
- Reinforced type
- Extra Reinforced type
- Response time less than 20 ms
- Zero-crossing switching technique
- Design suitable for 800x600mm panel
- Advantages of Switching with Static Contactor ;
- Prevention of sudden current and voltage pulses
- High reliability and durability
- Noise and EMG reduction
